New Low loader semi-trailer OZGUL 3-4 AXLE LOWER DECK PLATFORM

Chassis: steel

RACK

Made of high-strength steel box rack

level 1000,2000,3000,4000 mm Pneumatic operating extension from the centre

Rack is supported with 160-200 NPI axle beams that crosses rack

CHASSIS HYDRAULIC COMPONENT

Platform will be produce; Hydraulic up and down system

HYDRAULIC GOOSENECK

Gooseneck can be moved up and down position Hydraulicly for arrange fifth Wheel load and height

AXLE SHAFT

3-4 axle shafts with drum and air suspension with the capacity of 12-14 tons

are used

3. and 4th axles shaft can be self steering

Option; 3. and 4th axles shaft can be Hydraulic air suspension steering with Independent radio remote control

SUSPENSION

Parabolic double deck Z springs and dashpots

ELEVATING AXLE SHAFT

Remote operated elevating system for 1. And 4. Axles shaft in cabin

TIRES AND RIMS

235/75 R 17.5

245/70 R 17.5

295/60 R 22.5

12 R 22.5

315/80 R 22.5 sizes 20+1 tires are used

ELECTRICAL EQUIPMENT

It is suitable for SAE standards and Tüv regulations

Electricity is provided by 7 pin plug from vehicle

There are necessary traffic advisory and stoplights on both sides

There are backlights

brake lights

license plate lamps

trailer reflectors and orange warning lights on the sides

BRAKE EQUIPMENT

71/320/ewg ff brake system according to EC standards

Automatic slacks

2 spring brake chambers and 2 service brake chambers

4S / 3M EBS and RSS that provides safe driving system against rollover (Balance Control System)

Air leaks in trailer are blocked by Sweden patented Ruffels union system

KING-PIN

Steel king-pin which is 2” according to DIN 74080 standards and 3½” 42 CRMO4 according to DIN 74083 standards are used

CONVEYOR LEGS

On the front: 24 tons Mechanical trailer legs

On the behind: Manuel support legs

BACK ACCESS RAMP

Made from 160 NPU

With electric engine

Remote operated

Back legs with hydraulic piston

FLOOR

Diamond embossed sheet and solid floor on tires and sides

PAINT

Rack and superstructure are painted in paint drying oven by Washing + Sanding + 2+1 coat Acrylic Paint

COLOR

It will be specified according to customer request

STANDARD ACCESSORIES

2 x 8 expanding brackets(300+300 mm)

§ 2 x 8 load binding ring

§ 1 x tool box

§ 2 x Bike safety bar

§ 1 x Tire weld and holder

§ 1 x 60 lt capacity plastic water tank

§ 1 x Plate front panel(height: 500 mm)

§ 3 x Aluminum panels on the side in suspension beam area(height 500 mm)

OPTIONAL SPECIFICATIONS

European axle shaft group and all kind of equipments

Aluminum rims

Hydraulic suspension beam

Double spare tire conveyor

Fire extinguisher closet and fire extinguisher tube

Tire mark according to request

RAL color codes according to request
